7.5. DISMANTLING THE SECONDARY ON SWITCH CARD
OPERATION
DESCRIPTION
Dismantling the
secondary ON switch card
1. Switch off the equipment and disconnect the power supply plug
from the wall socket.
2. Remover the “Rear display cover”.
3. Remove the HR/HS receivers support cover
4.
Remove the front plastic angle pieces, under the polished
aluminium display frame.
5. R
emove the rear plastic angle pieces, under the polished
aluminium display frame. 2 screws, using a Phillips screwdriver.
6. Remove the plastic “V” guard under the display.
7. Remove the polished aluminium “V” guard. 3 screws, using a 4
mm hex key.
8. Remove the aluminium water bottle holder. 6 screws, using a 4
mm hex key.
9. It is now possible to remove the secondary ON button card. 4
screws, using a Phillips screwdriver.
