Technogym CROSS PERSONAL - Dismantling the Whole Display

CROSS PERSONAL: Service & maintenance manual - rev. 1.1
Page 7.2
7.2. DISMANTLING THE WHOLE DISPLAY
OPERATION
DESCRIPTION
Dismantling the
whole Display
1. Switch off the equipment and disconnect the power supply plug from
the wall socket.
2. Remover the “Rear display cover”.
3. Disconnect the following cables from the CPU: mains power and related
earth, aerial, AUX, HS, Fast Track, HR, audio OUT, amplifier power,
LAN inputs.
4. Loosen the 3 screws on the lower cover “forks”, onto which the HR
receiver and the HS card are slotted, using a 4 mm hex key (the central
3 of the 5 present).
NOTE:
during reassembly, reposition the HR receiver and the
HS card exactly as they were before.
5.
Loosen the 3 screws anchoring the client TGS/USB support plate,
using a Phillips screwdriver.
6. Remove the iPod docking station panel.
7. Unscrew the 4 screws anchoring the display board support plate (2 on
the right side and 2 on the left side), using a 5 mm hex key. Remove
the display unit.
NOTE: during reassembly, push the display unit upwards before
tightening the 4 screws.
Dismantling the
Cardio Receiver
1. Switch off the equipment and disconnect the power supply plug from
the wall socket.
2. Remover the “Rear display cover”.
3. Loosen the 3 screws on the lower cover “forks”, onto which the HR
receiver and the HS card are slotted, using a 4 mm hex key (the central
3 of the 5 present).
4. Remove the HR receiver and the HS card from the lower cover.
NOTE:
during reassembly, reposition the HR receiver and the
HS card exactly as they were before.
