CROSS PERSONAL: Service & maintenance manual - rev. 1.1
Page 2.8
CU331: iPod signal cable
(CPU Board– Docking Station)
Scheda CPU
CN26
Signal Colore Docking Station
1
+V bus USB
Black
14
2
GND bus USB
Black
13
3
TX - RX
Black
11
4
RX – TX
Black
12
5
CTS
Black
10
6
+5Vdc
Black
9
7
GND
Black
8
8
GND
Black
7
9
Video Gnd
Black
6
10
Video signal
Black
5
11
Audio L Gnd
Black
4
12
Audio L signal
Black
3
13
Audio R signal
Black
2
14
Audio R Gnd
Black
1
CU308: User USB port cable
(CPU Board –USB Port)
CPU Board
CN14
Signal Colour USB Port
1
+5 Vdc
Red
1
2
USB-
White
2
3
USB+
Black
3
4
GND
Green
4
5
Shield
Blue
5
CU611: HS board cable
(CPU Board –HS board)
CPU Board
CN24
Signal Colour
HS board:
HD4
1
+5 Vdc power supply
White
2
5
HS cardio signal
Brown
3
6
Gnd
Green
1
