Technogym CROSS PERSONAL - AUDIO SIGNAL AND AUDIO OUT CONTROL

CROSS PERSONAL: Service & maintenance manual - rev. 1.1
Page 2.9
CU613: IN/OUT Audio signal
(Amplifier - CPU Board – Headphone Jack)
Amplifier
J3
Signal Colour
Headphone
Jack
(Display)
Headphone
Jack
(Frame)
CPU
J5
1
Audio IN R
Yellow
2
2
Audio IN L/Power OFF
White
5
3
Gnd
Grey
1
4
Audio OUT L
Brown
4
5
Audio OUT R
Green
3
6
Power OFF
Brown
4
7
Audio OUT R
White
1
8
Audio OUT L/Power OFF
Brown
4
9
Gnd
Green
3
10
Audio IN L/Power OFF
White
5
11
Audio IN R
Green
2
12
Gnd
Yellow
1
CU614: AUX Audio/Video & Antenna signal cable
(CPU Board –AUX connector /Tuner Board – Antenna connector)
CPU Board
CN27
Signal Colour
AUX connector
board
1
n.c.
-
1
2
Audio IN LEFT
Black
2
3
Gnd IN LEFT
Black
3
4
Audio IN RIGHT
Black
4
5
Gnd IN RIGHT
Black
5
6
IN Video
Black
6
7
Gnd IN Video
Black
7
8
n.c.
-
8
Tuner
Segnale
Colore
Conn. Antenna
J12
Antenna
White
-
CU615: Amplifier power supply cable
(CPU board – Amplifier)
CPU board
CN15
Signal Colour
Amplifier:
J5
3
Gnd
White
2
6
+12 Vdc Power supply
Brown
1
