Page 6.25
Follow the chart step by step in order to make a correct diagnosis. In particular, pay attention to
the checks highlighted in the numbered boxes and listed here below:
(1) Carry out the Standard Settings, as described in the relevant paragraph of the Service menu.
(2) Mains-powered equipment: Insert the tips of the tester on the ends of the speed sensor.
If you have an oscilloscope, the signal that should be
measured is like the one indicated in Errore. L'origine
riferimento non è stata trovata., at about 80rpm user.
The speed signal can also be measured in a qualitative manner using a multimeter.
When the equipment is stationary, you should register a value of 0Vdc, which will tend
to grow as the speed increases.
(3) Perform a Low Kit SW Update, by first loading the Firmware (FW) and then the Brake
Table. At the end of the operation, launch the Standard Settings, to update the Low Kit
parameters.
