RUN 600 XTPRO: Service & Maintenance Manual - rev. 1.3
Page 7.32
Figure 7.20-3
8. Remove the LEAD SCREW NUT GROUP.
To reassemble the LEAD SCREW NUT
GROUP, carry out the above steps in reverse
order.
