9.5.1. MONITOR FUNCTION PARAMETERS
Parameter Description
d01 Motor output frequency
d02 Motor current draw
d04 Direction of movement
d05 Status monitor of intelligent terminal input signals
d06 Status monitor of intelligent terminal output signals
d07 “Converted” motor output frequency
d08 Monitor of last alarm condition
d09 List of the last error conditions
9.5.2. MODIFIED PARAMETER SETTINGS
The following table shows the parameters which must be configured with a different value from the
inverter defaults:
Parameter Description Value
F02 Acceleration 15
F03 Deceleration 15
A04 Maximum frequency setting 98
A81 Selection of AVR function 01
A82 Selection of voltage of AVR function for the motor 240
b12 Level of electronic thermal setting 8.00
b22 Level of overload restriction setting 12.00
b83 Carrier frequency setting (KHz) 16.0
b90 Dynamic braking usage ratio 20
C13 Condition of terminal 3 setting 01
C03 Function of terminal 3 setting 12
C41 Level of overload signal setting 8.00
H02 Motor data selection 01
H03 Motor capacity setting 1.5
H05 Motor constant K
p
setting 80
H20 Motor constant R1 setting 1.124
H21 Motor constant R2 setting 0.788
H22 Motor constant L setting 8.79
H23 Motor constant Io setting 3.65
H24 Motor constant J setting 20.0
H30 Motor constant R1 (Autotuning data) 1.124
H31 Motor constant R2 (Autotuning data) 1.500
H32 Motor constant L (Autotuning data) 8.99
H33 Motor constant Io (Autotuning data) 3.95
H34 Motor constant J (Autotuning data) 20.0
Before modifying the value of function C0, modify the value of function C13.
