RUN 600 XTPRO: Service & Maintenance Manual - rev. 1.3
Page 2.3
• RJ45-RS232 board
Name type of connector connection
CN1 Male panel connector DB9 to TGS reader
CN2 Panel RJ45 to Cardio Theater
CN3 Female panel connector DB9 to external device (not used)
CN4 Flat 10-pin to CPU board
• HS interface board
Name type of connector connection
HD2 Molex 3-pin to left hand sensor
HD3 Molex 3-pin to right hand sensor
HD4 Molex 3-pin to CPU board
• Power supply
Name type of connector connection
CN1 PANDUIT 6-pin to mains electricity supply
CN2 PANDUIT 8-pin to inverter interface board
• Inverter interface board
Name type of connector connection
CN1 AMP MATE-N-LOCK 6-pin F. to inverter
CN2 AMP MATE-N-LOCK 12-pin F. to CPU board
CN4 AMP MOD I 4-pin M to power supply
• Elevation board
Name type of connector connection
CN1 AMP MOD II 4-pin M. to photocell
CN2 AMP MATE-N-LOCK 4-pin F. to CPU board
CN3 AMP MATE-N-LOCK 6-pin F. to elevation motor – limit switches
CN4 AMP MATE-N-LOCK 2-pin F. to mains electricity supply
CN5 Sauro 2-pin to transformer
CN6 Sauro 2-pin to rectifier bridge
• Patch cord
Name type of connector connection
CN10 Faston between belt motor and inverter interface board
CN11 Faston between relay and CPU board/emergency button
