RUN 600 XTPRO: Service & Maintenance Manual - rev. 1.3
Page 11.5
Figure 11.1-2
Please note that even small departures from the above specifications may considerably impair
the accuracy of reception.
The optimal configuration is therefore that shown in the figures below:
• receiver housed inside the display:
Figure 11.1-3
• receiver positioned under the display:
