SYNCHRO EXCITE Class & Trend: Service & maintenance manual - rev. 2.0
Page 2.17
ELT-09: Handlebar sensor cable
(Connector board - Patch connector 5)
Connector board
J3
Signal Colour Patch connector 5
1 Gnd Braid 1
2 Sensor signal reference White 2
3 Left sensor signal Black 3
4 Gnd Braid 4
5 Sensor signal reference Green 5
6 Right sensor signal Red 6
ELT-10: Lever cable
(Patch connector – Lever)
Lever
Patch connector Signal Colour
Sensor Button
1 Sensor signal Clear Faston -
2 Gnd Braid - -
3 Lever button signal Green - 2
4 Sensor signal reference Black Faston -
5 Reference Brown - 4
6 + 5Vdc Power supply White - 1
ELT-16: HFU Receiver cable
(Display Board – HFU Receiver)
Display Board
CN3
Signal Colour HFU Receiver
1 +5 Vdc power supply White 2
7 Pulse (beat to beat) Black 4
8 Gnd Green 1
ELT-19: Hand sensor board cable - Lever buttons
(Display Board - Patch connector 6)
Display Board
CN4 CN5 CN6
Signal Colour
Patch connector
6
1 - - + 5Vdc Power supply Red 8
2 - - NA Green 7
3 - - NA Orange 1
5 - - Out pulse Blue 3
6 - - Reference Black 2
- 1 - + 5Vdc Power supply White 12
- 2 - Left lever button (-). Green 11
- 4 - Reference Brown 10
- - 1 + 5Vdc Power supply White 6
- - 2 Right lever button (+). Green 5
- - 4 Reference Brown 4
