ELT-23: Handlebar sensor cable
(Patch connector 5 – Sensors)
Sensors Patch
connector
Signal Colour
rh 1 rh 2 lh 1 lh 2
1 Gnd Braid - - - -
2 Sensor signal reference Black - - down down
3 Left sensor signal White - - up up
4 Gnd Braid - - - -
5 Sensor signal reference Black down down - -
6 Right sensor signal White up up - -
ELT-31: Hand sensor board cable - Lever buttons
(Patch conn. 6 - Hand sensor board - Lever connectors - Connector Board)
Lever
connector
Connector
board
Patch
connector
6
Signal Colour
Hand Sensor
Board
J3
RH LH J2 J4
8 + 5Vdc Power supply Red 4 - - - -
7 NA Green 1 - - - -
1 NA Orange 2 - - - -
3 Out pulse Blue 5 - - - -
2 Reference Black 3 - - - -
12 + 5Vdc Power supply White - - 6 - -
11 Left lever button signal
(–)
Brown - -
3
- -
10 Reference Green - - 5 - -
- Gnd Braid - - 2 1 -
- Reference Black - - 4 2 -
- Left sensor signal Clear - - 1 3 -
6 + 5Vdc Power supply White - 6 - - -
5 Right lever button signal
(+)
Brown -
3
- - -
4 Reference Green - 5 - - -
- Gnd Braid - 2 - - 1
- Reference Black - 4 - - 2
- Right sensor signal White - 1 - - 3
