Model 3550 LCR Meter Instruction Manual Service Information
Model 3550 Verification Procedure:
EQUIPMENT NEEDED
MODEL NUMBER
DESCRIPTION REQUIREMENTS
Agilent 42033A 100m: STANDARD RESISTOR
Four terminal BNC male
connectors. .863in centers
Agilent 42034A 1: STANDARD RESISTOR
Four terminal BNC male
connectors. .863in centers
Agilent 42035A 10: STANDARD RESISTOR
Four terminal BNC male
connectors. .863in centers
Agilent 42036A 100: STANDARD RESISTOR
Four terminal BNC male
connectors. .863in centers
Agilent 42037A 1k: STANDARD RESISTOR
Four terminal BNC male
connectors. .863in centers
Agilent 42038A 10k: STANDARD RESISTOR
Four terminal BNC male
connectors. .863in centers
Agilent 42039A 100k: STANDARD RESISTOR
Four terminal BNC male
connectors. .863in centers
Process Instruments 106 1M: STANDARD RESISTOR
Capable of measurement at
1KHz
Process Instruments 107 10M: STANDARD RESISTOR
Capable of measurement at
1KHz
Process Instruments 108 100M: STANDARD RESISTOR
Capable of measurement at
1KHz
Agilent 16089B Kelvin Clip Leads
Capable of measuring at 1KHz,
Through 100M ohms
Agilent 4284A Precision LCR Meter
Frequency Range: 20Hz to 1MHz
Four Terminal Pair *
Agilent 4285A Precision LCR Meter
Freq. Range: 75kHz to 30MHz
Four Terminal Pair *
Agilent 42090A Open Termination
Four terminal BNC male
connectors. .863in centers
Agilent 42091A Short Termination
Four terminal BNC male
connectors. .863in centers
Agilent 16385A .01 µF Standard Capacitor
Four terminal BNC male
connectors. .863in centers
Agilent 16386A .1 µF Standard Capacitor
Four terminal BNC male
connectors. .863in centers
Agilent 16387A 1 µF Standard Capacitor
Four terminal BNC male
connectors. .863in centers
*NOTE: All required accuracy specifications and features of the Agilent equipment are
not listed.
