Tegam 3550 - Table 5.5 B - Data Output Code Functions ContD

5-17
3550 LCR Meter Instruction Manual Programming and Interfacing
RS-232C
Table 5.5b - Data Output Code Functions cont’d:
Number Output Code Content
DISPLAY A Display Unit
H For Inductance Measurement
F For Capacity Measurement
R For Resistance, Impedance Measurement
18
S For Admittance Measurement
LO LOW NO-GO
GO GO
HI HIGH NO-GO
19
__ Comparator OFF (ASCII Code 5fh, outputted 2 times)
20
O
N
Over Range
Measurement Data Normal
D0 Loss Coefficient Measurement (D)
Q0 Quality Measurement (Q)
RS Equivalent Series Resistance Measurement(R
S
)
RP Equivalent Parallel Resistance Measurement (R
P
)
G0 Conductance Measurement (G)
X0 Reactance Measurement (X)
B0 Susceptance Measurement (B)
21
A0 Phase Angle Measurement (LJ)
+1.9999 Over Range, Measurement Data Abnormal
22
±*.**** Under Range, Measurement Data Normal
Measurement Data Exponent
E-09 n (10
-9
)
E-06 µ (10
-6
)
E-03 m (10
-3
)
E+00 (10
0
)
E+03 k (10
3
)
23
E+06 M (10
6
)
R For Equivalent Parallel + Series Resistance Measurement, and also Reactance
Measurement
S For Conductance and Susceptance Measurement
24
_ For Loss Coefficient, Quality Measurement, Phase Angle Measurement
LO LOW NO-GO
GO GO
HI HIGH NO-GO
25
__ Comparator OFF (ASCII Code 5Fh, outputted 2 times)
26
BIN* BIN Number Decision Result ( *:09)
If Comparator is OFF, then "____"(ASCII Code 5Fh, 4times)
GO TOTAL GO
NG TOTAL NO-GO
27
__ Comparator OFF (ASCII Code 5Fh, 2times)
28
C
R
+L
F
Delimiter. For RS-232C, only C
R
+L
F
