The Comparator cont’d:
BIN Operation cont’d
Nested Sorting Configuration
Nested sorting is typically used for tolerance-based sorting where an acceptable % or value range
is defined for each BIN #. First, the 3550 evaluates the measured value according to the defined
range of BIN 1. If the measured falls within the range of BIN 1 then the component is sorted into
BIN 1. If the measured value falls outside of the BIN 1 range then it is evaluated for BIN 2. If the
component value falls within the BIN 2 range then it is sorted into BIN 2. If not, then the 3550
proceeds the evaluation to BIN 3 and so on. If the measured value does not fall within any defined
ranges then the component will be sorted into BIN 0, the reject BIN.
Figure 4.6 Nested BIN Sorting
