Tegam 3550 - Monitor Output Format

5-18
3550 LCR Meter Instruction Manual Programming and Interfacing
RS-232C
Monitor Output Format
Output in Relation to Monitor Command "MON"
For all 10 panels, (0~9) the PANEL No., DISPLAY A Function, DISPLAY B Function, CIRCUIT MODE,
RANGE, Measurement Signal Frequency and Measurement Signal Voltage will be outputted and
divided by spaces. At the end, whether or not there is a Limit Value will be indicated as well.
Output Format Sample:
P0 _ L _ D0 _ R0 _ A _ 1.00E+03 _ OV _ 1.0000E+00V _ V1 _ -
P1 _ L _ D0 _ R0 _ S _ 1.00E+03 _ OV _ 1.0000E+00V _ V1 _ -
P2 _ L _ Q0 _ R1 _ S _ 1.00E+03 _ OV _ 1.0000E+00V _ V1 _ -
P3 _ L _ Q0 _ R2 _ S _ 10.0E+03 _ OV _ 1.0000E+00V _ V1 _ *
P4 _ L _ D0 _ R3 _ S _ 10.0E+03 _ OV _ 1.0000E+00V _ V1 _ *
P5 _ L _ D0 _ R4 _ S _ 10.0E+03 _ CV _ 5.0000E-01V _ V1 _ -
P6 _ L _ D0 _ R5 _ S _ 100.E+03 _ OV _ 1.0000E+00V _ V1 _ -
P7 _ L _ D0 _ R6 _ S _ 100.E+03 _ CC _ 1.0000E+00V _ V1 _ -
P8 _ L _ D0 _ R7 _ S _ 5.00E+06 _ OV _ 1.0000E+00V _ V1 _ -
P9 _ L _ D0 _ R7 _ S _ 2.21E+06 _ OV _ 1.0000E+00V _ V1 _ -
1 2 3 4 5 6 7 8 9 10 11 12 13
1 - Panel Number
2 - DISPLAY A Function
3 - DISPLAY B Function
4 - Range Number
5 - Measurement Circuit Mode
6 - Measurement Signal Frequency Temp. Value
7 - Measurement Signal Frequency Exponent
8 - Measurement Mode
9 - Measurement Signal Voltage Temp. Value
10 - Measurement Signal Voltage Exponent
11 - Measurement Data Averaging
12 - Comparator (*:ON -:OFF)
13 - Delimiter
NOTE: In the Output Format Sample, the "_" denotes a space (ASCII Code 20h).
