Model 3550 LCR Meter Instruction Manual Instrument Description
1-7
Performance Specifications cont’d:
Measurement Frequency
Table 1.2 – Model 3550 Measurement Frequencies
Frequency Range Resolution
42.0Hz ~99.9Hz 0.1Hz Steps
100Hz~999Hz 1Hz Steps
1.00kHz~9.99kHz 10Hz Steps
10.0kHz~99.9kHz 100Hz Steps
100kHz~999kHz 1kHz Steps
1.00MHz~5.00MHz 10kHz Steps
Measurement Frequency Accuracy
±0.01%
Measurement Signal Level
Table 1.3 – Model 3550 Measurement Amplitudes
Frequency Range Test Voltage
Range
Test Current Range
42.0Hz~1.00MHz 0.01~5.00Vrms 0.01~99.99mArms
1.01MHz~5.00MHz 0.05~1.00Vrms 0.05~20.00mArms
Open Terminal Voltage Mode
x Increment/Resolution 0.01V Steps
x Max. Shorting Current 99.99mA (Dependent on Measurement Frequency)
Fixed Voltage Mode
x Increment/Resolution 0.01V Steps
x Max. Shorting Current 99.99mA(Dependent on Measurement Frequency)
Fixed Current Mode
x Increment/Resolution 0.01mA Steps
x Max. Shorting Current 99.99mA(Dependent on Measurement Frequency)
