Tegam 3550 - Table 5.4 - Comparator Instructions

5-14
3550 LCR Meter Instruction Manual Programming and Interfacing
RS-232C
Table 5.4 - Comparator Instructions
Function Program Code Content Remarks
*C0 Comparator OFF
Comparator
C1 Comparator ON
CP0 Absolute Value Setting Absolute Value Setting Comparator
Comparator
Mode
CP1 % Setting % Setting Comparator
Bin Number BIN Sorting Category BIN No.(19)
Absolute Value
Setting
Limit Values
CALXXXX
CAHXXXX
CBLXXXX
CBHXXXX
DISPLAY A LOW
DISPLAY A HIGH
DISPLAY B LOW
DISPLAY B HIGH
XXXX: ±0.0000e00 ~ ±1.9999e08
Disabled Setting = "---------"
% Setting
Limit Values
CAPXXXX
CBPXXXX
PALXXXX
PBLXXXX
PAHXXXX
PBHXXXX
DISPLAY A Std. Value
DISPLAY B Std. Value
DISPLAY A Min. %
DISPLAY B Min. %
DISPLAY A Max. %
DISPLAY B Max. %
XXXX: ±0.0000e00 ~ ±1.9999e08XXXX:
±0.0000e00 ~ ±2.000e02
Disabled Setting = "---------"
*1) * indicates a initial setting
NOTE 1: As soon as "LIM" is sent, make sure that the system is ready to receive signals.
