3550 LCR Meter Instruction Manual Programming and Interfacing
RS-232C
Table 5.6b - Monitor Output Code Functions cont’d
Number Output Code Content
Limit Values( 15 Minimum, 16 Maximum )
XX: H (Inductance Measurement)
F (Capacity Measurement)
R (Resistance, Serial Equivalent Resistance, Parallel
Equivalent Resistance, Reactance)
S (Admittance, Conductance, Susceptance)
15
17
±**.***E+**XX
_ (Loss Coefficient, Quality, Phase Angle Measurement)
16
/ Divider for High and Low Limit Values (ASCII Code 2Fh)
CP0 Absolute Value Setting Mode
18
CP1 Percent Settings Mode
Percent Settings Standard Values
XX: H (Inductance Measurement)
F (Capacity Measurement)
R (Resistance, Serial Equivalent Resistance, Parallel
Equivalent Resistance, Reactance)
S (Admittance, Conductance, Susceptance
19
±**.***E+**XX
_ (Loss Coefficient, Quality, Phase Angle Measurement)
20
21
***.**%
Limit Values( 20 Low Value, 21 High Value)
***.**% has a setting range of 000.00%~200.00%
