5-21
3550 LCR Meter Instruction Manual Programming and Interfacing
RS-232C
Table 5.6a - Monitor Output Code Functions
Number Output Code Content
1
P* Panel Number( * :1~9)
L Inductance Measurement (L)
C Capacity Measurement (C)
R Resistance Measurement (R)
|Z| Impedance Measurement (|Z|)
2
|Y| Admittance Measurement (|Y|)
D0 Loss Coefficient Measurement (D)
Q0 Quality Measurement (Q)
RS Equivalent Series Resistance Measurement (R
S
)
RP Equivalent Parallel Resistance Measurement (R
P
)
G0 Conductance Measurement (G)
X0 Reactance Measurement (X)
B0 Susceptance Measurement (B)
3
A0 Phase Angle Measurement (LJ)
A Auto Circuit Mode
S Series Equivalent Circuit Mode
4
P Parallel Equivalent Circuit Mode
R0 Auto Range
R1 100mƻRange
R2 1ƻRange
R3 10ƻRange
R4 100ƻRange
R5 1kƻRange
R6 10kƻRange
R7 100kƻRange
R8 1MƻRange
5
R9 10MƻRange
6
**.*
*.**
***.
Measurement Frequency Temp. Value
e.g.) 42.0Hz ~"42.0": 100Hz~"100.": 1.00kHz~"1.00"
7
E+** Measurement Frequency Exponent
e.g.) "E+00" ĺ Hz: "E+03" ĺ kHz: "E+06" ĺ MHz
OV Open Terminal Voltage Measurement Mode
CV Fixed Voltage Measurement Mode
8
CC Fixed Current Measurement Mode
9
10
+*.****E±** Test Piece Voltage Temp. Value Exponent
e.g.) 1.00Vĺ"1.0000E+00": 0.10V ĺ "100.00E-03"
11
* Comparator ON
12
- Comparator OFF
13
C
R
+L
F
Delimiter, for RS-232C is C
R
+L
F
only
14
BIN* BIN Number ( * :0~9)
