Model 3550 LCR Meter Instruction Manual Instrument Description

1-6

Performance Specifications cont’d:

Basic Accuracy

0.1%

Display Specifications:

x Numeric Display (DISPLAY A)

L, C, R, |Z|, |Y| (4

digits)

x Numeric Display (DISPLAY B)

D, Q, R

, R

, G, X, B, Ǉ (4

digits)

x Numeric Display (DISPLAY C)

Frequency, Voltage, Current, Terminal Voltage, Terminal Current, PANEL (3 digits)

x Unit Prefix Display (DISPLAY A)

p, n, µ, m, k, M

x Unit Prefix Display (DISPLAY B)

n, µ, m, k, M

x Unit Display (DISPLAY A)

F, H, ƻ, S

x Unit Display (DISPLAY B)

ƻ, S, deg

x Unit Display (DISPLAY C)

Hz, kHz, MHz, V, mA

Switch Indicator Lamps

x RANGE – AUTO; UP; DOWN

x CIRCUIT MODE – AUTO; SER; PRL

x SHIFT

x DISPLAY C – V; I; CV/CC

x TRIGGER - INT; MAN/EXT

x SAMPLE
