3-8
Model 3550 LCR Meter Instruction Manual Quick Start Instructions
Setting the Percent Comparator
8. Input the BIN No.
After selecting the threshold value input mode, use the cursor key, [Ź] to highlight the bin
LED, and then press [1]~[9] to select the desired bin.
9. Input the Threshold Value for DISPLAY A
After entering the bin number, use the cursor key [Ź] to highlight DISPLAY A.
Enter the 5-digit threshold value for DISPLAY A using keys [0]~[9]. (The setting range is
from 000.00%~199.99%)
10. Input the Threshold Value for DISPLAY B
Enter the 5-digit threshold value for DISPLAY B using keys [0]~[9]. (The setting range is
000.00%~199.99%)
11. Finalizing the Setting
To finalize an upper limit, press [HIGH] or press [LOW] to finalize a low limit setting.
NOTE: Whether a high or low limit %comparator setting is defined is determined in step 7.
To input settings for other bins, return to Step 1 and repeat the process.
12. Invalidating the DISPLAY A or DISPLAY B Percent Comparator settings
To invalidate the settings, for threshold values, simply enter the Threshold Percent
Comparator Set Mode and move the cursor to any segment in DISPLAY A or DISPLAY B. Then
press [IGNORE] to invalidate the % comparator settings for that DISPLAY.
NOTES:
The comparator can only be set using panels 1~9. 0 cannot be used.
This procedure is only for the percent comparator setting. Note that the procedure for the
absolute value comparator is different.
Make sure the comparator mode is set for “Percent Mode” otherwise the procedure will not
work correctly.
After setting the limit values for the comparator, the measurement parameters for DISPLAY
A and DISPLAY B cannot be changed. This means that the measurement parameters must
be defined before the comparator settings.
For DISPLAY B, there are no units for D,Q, or LJ.
