GPIO connector
signal pinouts
The following t
able lists the signals and their function for each pin on the GPIO
connector.
Table 7: GPIO connector signal pinouts
Pin
Signal
Function
1
State – Primary Backup Output – high if Primary is selected, low
if Backup i
s selected
2
Primary f
ault
Output – g
oes low if a Primary fault is
present
3
Backup fault Output – goes low if a Backup fault is
present
4
State – Manual Auto Output – high if M anual mode is
selecte
d, low if Auto mode is selected
5
GND Ground
6
Power
fault
Outpu
t – goes low if a fault is preset in
the power subsystem as i ndicated by
the AC or D C LEDs on the supplies
7
Manual mode Input – drive this pin low to assert
Manual mode (10 KΩ pullup resistor)
8 Auto mode Input – drive this pin low to assert Auto
mode (10 KΩ pullup resistor)
9 Fault reset Input – drive this pin low to assert a
fault reset (10 KΩ pullup resistor)
10
Configurable fault Output – goes low if any fault selected
in t
he G PI EVENTS m enu are present;
also goes low during any watchdog
reboot
11
GND Ground
12 Not used
1
3
P
rimary select
I
nput – drive this pin low to select the
Primary source (10 KΩ pullup resistor)
1
4
B
ackup select
I
nput – drive this pin low to select the
Backup source (10 KΩ pullup resistor)
15 Not used
