Tektronix ECO8000 Series User Manual

Operating Basics
Table 14: Signal pinouts for the SPG8000 GPI/LTC connector and the TG8000 GPS7
module LTC/GP
I connector (cont.)
6
GND
7
LTC3–
8
LTC2–
9
GND
10
LTC1–
11
12
LTC3+
13
LTC2+
14
LTC1+
15
LTC4+
Table 15: Signal pinouts for the SPG8000 GPI connector
Pin
Signal
1
GND
2
GPO1
3
GPO2
4
GPI
5
5V
6
GPO3
7
Preset1
8Preset2
9Preset3
Table 16: Signal pinouts for the TG8000 GPI port
Pin
Signal
1
GPI1
2
GPI2
3
GPI3
4
5
6
GPO
7
8
GND
ECO8000 Series Automatic Changeover Unit User Manual 33

Tektronix ECO8000 Series Specifications

General

Brand	Tektronix
Model	ECO8000 Series
Category	Control Unit
Language	English
