Menus
STATUS. Select
this menu item and press the ENTER button to access the
STATUS menu, which you can use to view instrument faults and the Event L og
contents. (See page 56, STATUS menu.)
CH1 ELSW < status>. Select this menu item and press the left (◄)orright(►)
arrow button to select the desired BNC or LT C (Option LTC only) channel. After
you select t
he desired channel, press the ENTER button to access the menu for the
selected channel, which you can use to view and configure the channel settings.
(See page 62, CHANNEL menu.)
The top line of the display lists the following information:
The chann
el or LTC number.
The type of channel: ELSW, Relay, or LTC.
The channel status or the current threshold level. If the selected channel is
disabled, “DISABLED” is displayed after the channel type. If the selected
channe
l is enabled, then the current threshold level for the channel is
displayed. For example, if the threshold is set to NTSC, then “NTSC” will
be displayed after the channel type.
SYSTEM CONFIG. Select this menu item and press the ENTER button to access
the SYSTEM CONFIG menu, which you can use to view or configure various
inst
rument settings. (See page 65, SYSTEM CONFIG menu.)
ECO8000 Series Automatic Changeover Unit User Manual 55
