DISPLAY/HARMONICS
THS710A, THS720A, THS730A & THS720P User Manual
3–19
Measurement Readouts. The area to the right of the graticule contains
measurement readouts similar to scope mode display. Refer to
page 3–53 for more information.
Waveform Readout Lines. The readout lines below the graticule contain
specific information about the waveform similar to scope mode
display. Refer to page 3–51 for more information.
Graticule Area. The graticule area contains a bargraph of the
harmonics. To display the harmonic content of the voltage
waveform, press CH 1. To display current harmonics, press CH 2.
Fundamental Harmonics
To Next Page
