AUTORANGE
3–8
THS710A, THS720A, THS730A & THS720P User Manual
AUTORANGE
Autorange automatically adjusts setup values to track a signal. If the
signal changes, the setup continues to change to track the signal.
Autorange works independently in scope and meter modes. Refer to
page 3–16 for additional autorange information for the THS720P.
The following controls are preset when you first select the autorange
function.
Scope Mode Meter Mode
Acquire mode: Sample
none
Stop acquire after: HOLD button only
Vertical coupling: DC (if GND was
selected)
Bandwidth: Full
Invert: Off
Horizontal position: Centered
Horizontal magnification: Off
Trigger type: Edge
Trigger source: Lowest numbered
channel displayed
Trigger coupling: DC
Trigger slope: Positive
Trigger holdoff: Minimum
Display style: Vectors
Display format: YT
