METER Mode

THS710A, THS720A, THS730A & THS720P User Manual

3–39

METER Mode

Press the METER button to enter meter mode. The meter reading

and statistics update about three times per second.

VAC — —

VDC — —



— —

(continuity)

—

(diode)

—

The meter-mode display, shown below, is divided into three sections.

The next two pages identify the content of each section in detail.

Graticule area

Measurement

readout areas

Status line
