General-Purpose Application Examples
2–16
THS710A, THS720A, THS730A & THS720P User Manual
Displaying an Unknown Signal
You need to see a signal in a circuit, but you have no previous
knowledge of the signal amplitude, frequency, or shape. Connect the
TekScope instrument to quickly display the signal.
Ch 1
