HOLD
3–26
THS710A, THS720A, THS730A & THS720P User Manual
HOLD
Press the HOLD (RUN/STOP) button to stop and start data
acquisition. Because scope mode and meter mode have independent
acquisition states, the HOLD button operates independently for these
two modes.
Hold Function in Scope Mode
In scope mode, the function of the HOLD button depends on the
Stop After selection in the acquire menu.
Acquire Menu Setting Functions of HOLD Button
Stop After HOLD Button Only First press stops waveform acquisi-
tion.
Second press restarts waveform
acquisition.
Stop After Single Acquisition
Sequence
Any press starts a new acquisition
sequence. The acquisition sequence
stops automatically.
Hold Function in Meter Mode
In meter mode, pressing the HOLD button once freezes the meter
reading, the measurement statistics (MIN, MAX, and AVG), and the
data logger display.
A second press of the HOLD button resets and restarts the data
logger display and measurement statistics, and then restarts the
meter readings.
