HARD COPY
3–22
THS710A, THS720A, THS730A & THS720P User Manual
HARD COPY
You can print a hard copy of the display if a printer is connected and
properly configured. Press the HARD COPY button to start printing.
If you do not want menus to show, press CLEAR MENU before you
press HARD COPY. You cannot change instrument settings while the
hard copy is printing.
Connecting a Printer
Use the RS-232 cable to connect the printer to the RS-232 port on
the side of the TekScope instrument. The RS-232 accessory kit
includes an adapter for 9-pin RS-232 connectors.
H Refer to RS-232 System on page 3–64 for information about
setting the TekScope instrument for RS-232 communication with
your printer.
H Refer to the user manual for your printer for information about
setting its baud rate and any other required parameters.
H Refer to Making the Connection on page 3–24 for information
about RS-232 cables and adapters.
Printer
TekScope instrument
RS-232 cable
To Next Page
