General-Purpose Application Examples
2–32
THS710A, THS720A, THS730A & THS720P User Manual
Triggering on a Video Signal
The image quality is poor on a video monitor in a closed-circuit
security system that uses the NTSC broadcast standard. Set up the
TekScope instrument to display and trigger on the odd field of the
video waveform coming into the monitor.
Ch 1
Incoming video signal
75  terminator
