Tektronix TekScope THS710A User Manual

Power-Measurement Application Examples
2–48
THS710A, THS720A, THS730A & THS720P User Manual
Measuring Motor Start-Up Current
A circuit breaker trips when a motor starts. Connect the TekScope
instrument to measure the transient current drawn by the motor
before the circuit breaker trips.
Ch 1
100 mV/A
