General-Purpose Application Examples
2–24
THS710A, THS720A, THS730A & THS720P User Manual
Triggering on a Missing Data Pulse
A positive-going TTL data pulse, 20 ms wide, should occur at least
once every millisecond. The circuit is not working correctly and you
suspect an occasional missing pulse. Set up the TekScope instrument
to find the missing pulse.
