General-Purpose Application Examples
THS710A, THS720A, THS730A & THS720P User Manual
2–23
Setup to Measure Propagation Delay
S
PE
CH 1
CH 2
AUTO
RANGE
1
CURSOR Cursor
Function
V Bars Adjust first
cursor, press
TOGGLE,
and then
adjust second
cursor
1
If necessary, adjust the SEC/DIV rocker to optimize display for
the propagation delay measurement.
Set one cursor to the active edge of the chip-select signal and the
second cursor to the data output transition. Read the propagation
delay in the cursor readout.
Going Further
The above example uses cursors to take relative timing measure-
ments (D-seconds) between two different waveforms. If you are
measuring just one waveform, select the Paired cursor function to
measure D-volts and D-seconds at the same time.
