Tektronix TekScope THS710A User Manual

Appendix D: Performance Verification
D–2
THS710A, THS720A, THS730A & THS720P User Manual
Test Record
Serial
Number
Procedure Performed by Date
Test Passed Failed
Self Test
Oscilloscope Tests Low Limit Test Result High Limit
C
hann
e
l 1
DC esre
5 mV/div 34.05 mV 35.95 mV
DC
M
e
a
s
u
re
-
ment Accu-
r
500 mV/div 3.405 V 3.595 V
me A
racy
2 V/div
13.62 V 14.38 V
10 V/div 68.1 V 71.9 V
C
hann
e
l 2
DC esre
5 mV/div 34.05 mV 35.95 mV
DC
M
e
a
s
u
re
-
ment Accu-
r
500 mV/div 3.405 V 3.595 V
me A
racy
2 V/div
13.62 V 14.38 V
10 V/div 68.1 V 71.9 V
Channel 1 Bandwidth 425 mV —
Channel 2 Bandwidth 425 mV —
Sample Rate and Delay Time
Accuracy
–4 divs +4 divs
Channel 1 Edge Trigger
Sensitivity
Stable trigger —
Channel 2 Edge Trigger
Sensitivity
Stable trigger —
