THS710A, THS720A, THS730A & THS720P User Manual
B–1
Appendix B: Factory Setup
The table below lists the state of the TekScope instrument after you
recall the Factory Setup.
Control Changed by Factory Setup to
Acquire mode Sample
Acquire stop after HOLD button only
Acquire # of averages 16
Acquire # of envelopes 8
Channel selection Channel 1 on, all others off
Cursor H Bar 1 position –3.2 divisions from the center
Cursor H Bar 2 position +3.2 divisions from the center
Cursor V Bar 1 position –2 divisions from the center
Cursor V Bar 2 position +2 divisions from the center
Cursor function Off
Cursor time units Seconds
Delayed time base time/div
50 ms/div
Delay time, delayed runs after main 200 ns
Data logger position 0 V
Data logger rate 30 s/div
Data logger zoom Off
dB reference voltage 1 V
dBm into impedance
50 W
Display format YT
Display graticule type Full
Display contrast 50%
