Appendix B: Factory Setup
B–2
THS710A, THS720A, THS730A & THS720P User Manual
Control Changed by Factory Setup to
Display style Vectors
Display trigger “T” On
Display accumulate time 500 ms
DMM mode – autorange Off
DMM function DC volts
DMM mode – scope on/off Off
Edge trigger coupling DC
Edge trigger level 0.0 V
Edge trigger slope Rising
Edge trigger source Channel 1
Harmonics (THS720P) Off
Horizontal – main trigger position 50%
Horizontal – Mag Off
Horizontal – time base Main only
Main time base time/div
500 ms/div
Math waveform function CH1 + CH2
Measure High-Low Setup Histogram
Saved setups No change
Saved waveforms No change
Scope/DMM mode Scope mode
Scope mode – autorange Off
Scope mode – meter on/off On
Trigger holdoff Minimum (495 ns)
Trigger mode Auto
