THS710A, THS720A, THS730A & THS720P User Manual
2–1
Functional Overview
This section covers the following topics:
H Understanding the front panel
H Using scope mode
H Using meter mode
H Connecting and using the probes
H Taking floating measurements
You can find specific information about each of the controls in the
Reference chapter of this manual.
Understanding the Front Panel
The front panel has buttons for the functions you use most often and
menus to access more specialized functions. With the autorange
feature, you can setup the TekScope instrument automatically in both
scope and meter modes.
Using the Menu System
To use the menu system, follow the steps shown on the next
two pages.
