General-Purpose Application Examples
2–22
THS710A, THS720A, THS730A & THS720P User Manual
Measuring Propagation Delay
You suspect that the memory timing in a microprocessor circuit is
marginal. Set up the TekScope instrument to measure the propaga-
tion delay between the chip-select signal and the data output of the
memory device.
D: 12.6 ns
Ch 1 Ch 2
Data CS
