METER Mode
3–40
THS710A, THS720A, THS730A & THS720P User Manual
Status Line
The status line across the top of the display contains acquisition
information. The overrange indicator warns when an overvoltage is
applied to the input.
Acquisition readout Overrange indicator
The table below shows examples of the acquisition readout.
Acquisition
Readout
Explanation
A
c
q
ui
s
ition
r
unning with auto
r
ang
e
f
unction on (
AUTO
RANG r ff R r q s s s ed d
RANG
E) o
r
o
ff
(
R
un), o
r
ac
q
ui
s
ition i
s
s
topp
ed
(Hol
d
)
Saved data is recalled for display (from location 7)
while acquisition runs in the background
Acquisition mode for data logger
