SCOPE Mode
THS710A, THS720A, THS730A & THS720P User Manual
3–49
Status Line
The status line across the top of the display contains acquisition and
trigger information.
Trigger statusAcquisition readout Additional items
The table below shows acquisition readout examples that are
displayed when acquisition is running. When you press HOLD to
stop acquisition, the readout shows the number of waveforms
acquired since acquisition was last stopped.
Acquisition
Readout
Explanation
A
c
q
ui
s
ition
r
unning with auto
r
ang
e
f
unction on (
AUTO
RANG r ff R
RANG
E) o
r
o
ff
(
R
un:)
Current sample rate
Acquisition mode
The table below shows the meaning of the trigger status indicators.
Trigger Status Explanation
Free-running in Auto trigger mode
Waiting for trigger in Normal trigger mode
Acquiring new pre-trigger data
