Tektronix TekScope THS710A User Manual

Appendix D: Performance Verification
D–14
THS710A, THS720A, THS730A & THS720P User Manual
Check Channel 1 Edge Trigger Sensitivity
1. Set up the TekScope instrument using the following steps:
S
CO
PE S
A
VE/
RECALL
Recall Saved
Setup
Recall Factory
Setup
—
OK Recall
Factory
—
ACQUIRE Acquire Mode Average Set to 16
TRIGGER Trigger Mode Normal —
ME
A
S
Gating & High-
Low Setup
High-Low
Method
Min/Max
Select
Measrmnt
Ampl*
—
OK Select
Measrmnt
—
* You may need to press Select Page to display this selection.
2. Connect the TekScope instrument to the leveled sine wave
generator as shown below.
Leveled
sine wave
generator
Ch 1
Output
50  feedthrough
terminator
BNC cable
