Appendix D: Performance Verification
D–16
THS710A, THS720A, THS730A & THS720P User Manual
Check Channel 2 Edge Trigger Sensitivity
1. First check the channel 1 edge trigger sensitivity using the
previous test. Then, perform these additional steps to check the
channel 2 edge trigger sensitivity.
S
CO
PE
CH 1
—
—
—
WAVE-
FORM
OFF
CH 2
TRIGGER Trigger Source Ch2
ME
A
S
Gating & High-
Low Setup
High-Low
Method
Min/Max
Select
Measrmnt
Ampl*
—
OK Select
Measrmnt
—
* You may need to press Select Page to display this selection.
2. Connect the TekScope instrument to the leveled sine wave
generator as shown below.
Leveled
sine wave
generator
Ch 2
Output
50  feedthrough
terminator
BNC cable
