Appendix D: Performance Verification
D–18
THS710A, THS720A, THS730A & THS720P User Manual
Check DC Voltage Accuracy
1. Set the DC voltage source output level to 0 V.
2. Set up the TekScope instrument using the following steps:
METER — VDC —
3. Connect the TekScope instrument to the DC voltage source as
shown below.
+–
DC voltage
source
Banana cables
To Next Page
