Appendix D: Performance Verification
D–20
THS710A, THS720A, THS730A & THS720P User Manual
Check AC Voltage Accuracy
1. Set the AC voltage source output level to 0 V.
2. Set up the TekScope instrument using the following steps:
METER — VAC —
3. Connect the TekScope instrument to the AC voltage source as
shown below.
AC voltage
source
Banana cables
To Next Page
