Glossary
Glossary–6
THS710A, THS720A, THS730A & THS720P User Manual
Menu
A set of labels shown in the display to identify the functions of
the bezel buttons. The specific menu contents depend on the
menu button you press.
Motor Trigger
Triggering on the rising or falling edge of a bipolar, motordrive
waveform.
Normal Trigger Mode
A mode where the oscilloscope does not acquire a waveform
record unless a valid trigger event occurs. It waits for a valid
trigger event before acquiring waveform data.
Paired Cursors
Two cross-shaped cursors that automatically track the vertical
values of a waveform when you adjust their horizontal positions.
The oscilloscope displays the voltage value and time value
between the paired cursors.
Pixel
A visible point on the display. The display is 320 pixels wide by
240 pixels high.
Pop-Up Menu
A submenu of a menu. Pop-up menus temporarily occupy part
of the waveform display area and present choices associated
with the menu item selected. You can cycle through the options
in a pop-up menu by repeatedly pressing the menu button
underneath the pop-up.
