Appendix A: Specifications
Table 6: Oscilloscope Inputs (cont.)
Characteristic Description
Trigger and Delay
Trigger modes
Automatic, Edge, Video, Pulse Width, N-Cycle
Trigger delay up to +1200 divisions
Pre trigger view
one full screen length
Delay –12 div to +1200 div
Maximum delay
60 s at 5 s/div
Automatic Auto-Level Trigger
Source Ch1, Ch2, Ch3, Ch4
Slope Positive, Negative, Dual (either positive or negative)
Edge Trigger
Screen update Auto, On Trigger, Single Shot
Source Ch1, Ch2, Ch3, Ch4
Slope Positive, Negative, Dual (either positive or negative)
Trigger level control range ±4 divisions
Ve rtical trigger level indicator
error
±0.5 divisions
Horizontal trigger level indicator
error
±1 sample
Trigger N-cycle range 2–99 cycles
Trigger sensitivity
DC to 5 MHz at >5 mV/div
0.5 divisions
DC to 5 MHz at 2 mV/div and 5 mV/div
1 division
THS3024
200 MHz 1 division
250 MHz 2 divisions
THS3014
100 MHz 1 division
150 MHz 2 divisions
Video Trigger
Standards PAL, PAL+, NTSC, SECAM, N on-interlaced
Modes
Lines, Line Select, Field 1 or Field 2
Source Ch1
Polarity Positive, Negative
Sensitivity
0.7 division sync level
84 THS3000 Series Oscilloscopes User Manual
