TEM Aligna 4D - 12 Delivery Content; Aligna Control Unit and Manual; Detector Delivery Contents

Aligna
®
4D User Manual
74 / 84
12 Delivery content
Please check the Aligna
®
system on delivery for damaged or missing items.
12.1 Delivery content Aligna
®
:
 Aligna
®
Control unit
 Aligna
®
User Manual
 If a piezo-based system was ordered (PiA or MoPiA):
SubD25   2x HD 15 (labeled as “piezo actuators”,
"A1", "A2")
additional ones, if more than two piezo drivers are ordered
 in the case of In/Out Modules: HD15 male/male cable for Motors, “Inputs", "Outputs"
 power supply cord (European, American version, others on demand)
12.2 Delivery content PSD 2D:
 PSD 2D Detector box (different types of detector sizes and properties)
Regarding PSD type with or without mechanical alignment possibilities
 HD15 male/male cable for PSD (labeled as “PSD 1”)
 (power supply is overtaken by Aligna
®
4D or µAligna
®
)
12.3 Delivery content PSD 4D e:
 PSD 4D e Detector system
 HD15 cable male/female, labeled as "PSD 1" (or PSD 2, 3,…)
 Y adapter (labeled as “PSD 1” "PSD A", "PSD B")
 (power supply is overtaken by Aligna
®
4D or µAligna
®
)
12.4 Delivery content PSD 4D i:
 PSD 4D i Detector system
 HD15 male/male cable for PSD (labeled as “PSD 1”)
 (power supply is overtaken by Aligna
®
4D )
12.5 Delivery content BeamScan OneInch:
 BeamScan 2D or BeamScan 2D One Inch or BeamScan 2D 4M
(depending on order: with or without mirrors)
 HD15 male/male cable (labeled as “A1” or "A2", "A3", A4" for second
beam, etc.)
