TEM Aligna 4D - Page 81

Aligna
®
4D User Manual
81 / 84
Cable requirements: >= 0.09 mm², >= 20 V
14.1.2.16 Piezo Actuator Connectors ("A1", "A2", "A3", "A4"):
Cable requirements: >= 0.09 mm², >= 150 V
14.1.2.17 Piezo Driver
1
6
11
Piezo X
2
7
12
Piezo Y
3
8
13
(Piezo Z, 3D actuator)
(Piezo X2, 4D actua-
tor)
4
9
14
(Piezo Y2, 4D actua-
tor)
5
10
Piezo GND
15
