© 2011 Thorlabs
149Appendix
7.4
Technical Data
7.4.1
Technical Data BC106
All technical data are valid at 23 ± 5°C and 45 ± 15% rel. humidity
Operating Temperature
+ 5 ... + 35 °C
Storage Temperature
- 40 ... + 70 °C
Warm-up time
not required
Model
BC106-UV
BC106-VIS
Wavelength Range
190 - 350 nm
1)
350 - 1100 nm
Coating
Lumigen
none
Power Range
50 fW - 1 W
2)
1 fW - 1 W
3)
Sensor
2/3" EXview HAD
TM
CCD Sensor
Sony ICX285AL, window removed
Aperture Size
8,77 x 6,6 mm, max.
Beam Diameter
30 µm - 6,6 mm
Camera Resolution
1360 x 1024 pixel max., ROI selectable
Pixel Size
6,45 µm x 6,45 µm
Image Digitization
8 bit (0 - 255 digits) or
12 bit (0 - 4095 digits)
Signal to Noise Ratio
62 dB
Shutter
Global
Exposure Range
20 µs 1 s
Gain Range
1x - 16x
Frame Rate
max. 10 fps @ full resolution
4)
>27 fps @ 640 x 480 pix
4)
>43 fps @ 320 x 240 pix
4)
Attenuation Filters
(nominal values, on filter
wheel)
20, 40 dB VIS
20, 40 dB UV
10, 20, 30, 40 dB VIS
Image Capture Modes
single frame, continuous, hardware triggered
Sensor Distance to
Surface
16.7 mm (6.65")
Compatible Light
Sources
cw, pulsed
Pulse Frequency
1 Hz - 50 kHz (single pulse exposure),
unlimited (multi pulse exposure)
Trigger Input
TTL level , BNC jack
5)
Trigger Delay
42 µs - 1 s, programmable
